رافعة هيدروليكية مقصية Skyjack SJ 4620 8.1m Schaarhoogwerker / scissor lift

Specification Details
Manufacturer Skyjack
Model SJ4620 (SJIII 4620)
Year of Manufacture 2007
Machine Type Electric Scissor Lift
Drive System 24V DC Electric
Application Indoor use and level surfaces
Certification CE Marked (European version)

Performance

Specification Details
Maximum Working Height 8.10 m (26 ft 7 in)
Maximum Platform Height 6.10 m (20 ft)
Platform Capacity 590 kg (1,300 lb)
Maximum Occupants 3 persons
Gradeability 25%
Travel Speed (Stowed) Approx. 2.9 km/h
Travel Speed (Raised) Approx. 1.0 km/h

Platform

Specification Details
Platform Length 2.13 m
Platform Width 1.07 m
Extension Deck Length 1.20 m
Total Extended Platform Length Approx. 3.33 m

Dimensions

Specification Details
Overall Length 2.31 m
Overall Width 1.17 m
Overall Height (Rails Up) 2.07 m
Wheelbase Approx. 1.75 m
Ground Clearance Approx. 0.10 m

Weight

Specification Details
Machine Weight 1,860 kg
Maximum Platform Load 590 kg

Tires and Drive

Specification Details
Tire Type Solid Non-Marking Tires
Tire Size 16 x 5 x 12
Drive Configuration 2-Wheel Drive
Inside Turning Radius Approx. 0.71 m
Outside Turning Radius Approx. 2.64 m

Safety Features

* Proportional controls
* Emergency lowering system
* Tilt alarm with drive cut-out
* Pothole protection system
* Automatic braking system
* Overload protection
* Dual holding valves on lift cylinders
* Emergency stop controls at both platform and ground stations

Electrical System

Specification Details
Power Supply 24V DC
Battery Pack 4 × 6V Deep-Cycle Batteries (configuration may vary)
Charger On-board Automatic Battery Charger

Transport Information

Specification Details
Transport Length 2.31 m
Transport Width 1.17 m
Transport Height 2.07 m
Transport Weight 1,860 kg

= More information =

Drive: Wheel
CE mark: yes
General condition: average
Technical condition: average
Visual appearance: average
Please contact Bas Sindorf for more information
